Trimble S - Transmitter and receiver fibre adjustment - collimator 79592001

Chapter 6
Adjustment and verification
Trimble S, VX, SPS & RTS Service Manual6 - 60 P/N 57150002, Revision 5.0
F
Tools and equipment
Transmitter and receiver fibre adjustment - collimator 79592001
Performance
Description Part number
Collimator bench with CCD camera - 79592001
Illumination RX S6/5600 79773001
Light cover centre unit 79775001
Light cover front lens 79556001
GDM Collimator - T71601480
Attenuator Greyfilter TX for GDM collimator (T71601480) 59017001
Instrument holder for GDM collimator (T71601480) 59000026
Reticle illumination tool 79706001
Illumination RX S6/5600 79773001
Light cover centre unit 79775001
Light cover front lens 79556001
Other tools
Torx screw driver Local tool
Screw driver slotted screw head Local tool
Hexagon screw driver (ball tipped) Local tool
Tweezers Local tool
TCXO calibration tool 79560001
Frequency counter 0,1 Hz resolution (PM6685/411 Fluke or similar) local equipment
Item Performance Description Result Notes
1 Prepare instrument and
collimator.
A. Place the instrument
on Collimator.
B. Set the collimator
wave length to 3.
C. Make suer the
collimator is aligned,
see page 6-32.
Transmitter and
receiver boards are
inserted. Cables are
connected and the
fibres mounted.
2 Remove greywedge
assembly.
See Fig. 6-56 on page 6-
62 .
3 Start up instrument /
PASS.
See page 7-3 how to set-
up the instrument.
