Chapter 4
Troubleshooting
Trimble S6, S8, VX, SPS & RTS Service Manual4 - 6 P/N 57150002, Revision 4.0
F
Check basic function
Select Check basic functions check box for EDM and Tracker functions.
The User actions box is now active to check the Distance meter and Tracker functionality. The
selection of the Distance meter settings (Target, Mode, Pointer) together with the Tracker settings
(Target, Target-ID, Autolock) can be made.
Summary of status for Check basic functions
* Option depend on Trimble S8 configuration.
Fig. 4-5 Check basic functions
After pressing the
Start button the results will appear in the Measurement results window.
Measure
mode
EDM target EDM
mode
Pointer Tracker target ID Autolock
DR
DR STD
TRK
ON
OFF
High Power Laser*
--ON
OFF
Prism &
Tracker
Prism STD
TRK
ON
OFF
High Power Laser*
Passive - ON
OFF
Prism &
Tracker
Prism STD
TRK
ON
OFF
High Power Laser*
Active 1 -
10
ON
OFF
Prism &
Tracker Long
Range
Long Range* STD
TRK
ON
OFF
Passive - ON
OFF
