Trimble S - Distance unit - High Precision; DR Standard; Replacement of Transmitter unit

Chapter 5
Maintenance and Repair
P/N 57150002, Revision 5.0 5 - 91 Trimble S, VX, SPS & RTS Service Manual
F
Distance unit - High Precision / DR Standard
• Replacement of Transmitter unit
• Replacement of Transceiver board
• Replacement of Switch motor
• Replacement of Greywedge motor
• Replacement of EDM Frame unit
Tools and equipment
Replacement of Transmitter unit
Performance
Description Part number
Torque wrench 30 Ncm T71600279
Torx T6, T7 & T8 bit Local tool
2 x Torx T8 screw driver Local tool
Torx T30 screw driver Local tool
Screw driver 2 mm Local tool
Hexagon screw driver 0,9 & 0,7 mm Local tool
2 x Allen key 1,5 mm Local tool
Allen key 1,3 mm Local tool
Straight point Tweezers Local tool
Item Performance Action Result Notes
1 Remove handle. Use a torx T30 screw
driver.
2 Remove distance and
tracker unit cover.
See page 5-3. See “General Safety”
on page 1-5..
3 Remove Tracker
transmitter board.
A. Turn center unit to face
two.
B. Remove the fixing
screw.
C. Disconnect tracker
transmitter board.
D. Remove the spacer.
See Fig. 5-88 on page 5-
92 .
