Chapter 5
Maintenance and Repair
Trimble S, VX, SPS & RTS Service Manual5 - 108 P/N 57150002, Revision 5.0
F
Fig. 5-107 Location of coax cable
Replacement of Transmitter unit
Replacement of transmitter unit follows the same procedure as for Trimble S6 Total Station with
High Precision/DR Standard distance units, see page 5-91.
Note – The Transmitter unit of the trimble S3 Total Station with DR distance unit is a class 3R product
marked with a laser warning label
Fig. 5-108 Location of laser warning label
Coax cable, here marked red
