Chapter 6
Adjustment and verification
Trimble S, VX, SPS & RTS Service Manual6 - 206 P/N 57150002, Revision 5.0
F
Service interval check list
Delivery test
[ ] 8. Radio range & short range test, see page 6-3.
[ ] 9. OEM instruments only, start up instrument without TCU and verify that
the OEM option is available in the face2 display, see page 3-60.
[ ] 10. Set service interval, see page 6-201
[ ] 11. Save constants, see page 6-6
[ ] 12. Save event log, see page 4-2
[ ] 13. Clear event log, see page 4-4
[ ] 1. Regreasing of centre unit axes, see page 5-50
[ ] 2. Check Service Bulletins for updates
[ ] 3. Run all test in Maintenance & Service
[ ] 4. Run through the instruments check list service/repair, see page 6-203
[ ] 1. Visual inspection
[ ] 2. Check distances according to specification
[ ] 3. Check angles according to specification
[ ] 4. Check servo knob function
[ ] 5. Check tracker function - Autolock
[ ] 6. Check tracker & radio function - Robotic
[ ] 7. Perform HA/VA collimation, see page 6-47
[ ] 8. Perform Trunnion axis correction, see page 6-48
[ ] 9. Perform Auto focus calibration (Not available on all instruments), see
page 6-180
[ ] 10. Perform Tracker collimation test, see page 6-147
[ ] 11. Perform Vertical oscillation compensation, see page 6-25
[ ] 12. Set service interval, see page 6-201
[ ] 13. Save constants, see page 6-6
[ ] 14. Check accessories
