Trimble S - Centre Unit - Tracker Long Range; High Power Laser Pointer

Chapter 8
Replacement Parts & Tooling
P/N 57150002, Revision 5.0 8 - 27 Trimble S, VX, SPS & RTS Service Manual
F
Centre Unit - Tracker Long Range / High Power Laser Pointer
Centre Unit - Tracker Long Range / High Power Laser Pointer
Item Description Part number Qty
1 TLR Transmitter unit 79008019 1
2 HPL Transmitter unit 79011019 1
3 Package Washer, 20p 79000241 3
4 Package Screw STS M2.5 x 10 A2-70 (20p) 79000307 5
5 OTC2 board 79018019 1
1/2
3
6
4
7
6
10
11
12
4
8
5
9
