Chapter 6
Adjustment and verification
P/N 57150002, Revision 5.0 6 - 159 Trimble S, VX, SPS & RTS Service Manual
F
Focusing of Video Camera
Performance
2 Establish the
Calibration targets 1 &
2.
Mount the two targets
in the required
distances.
Care for stable and
sufficient illumination
of the Calibration
targets for setup and
during the calibration
process.
Tolerances:
Distances:
3m ±0,5m
10m ±0,5m
Perpendicular to
optical axis:
<10gon
Avoid a target set up
close to a window or
other illumination
sources which can
influences the
exposure function and
finally the calibration.
It is very important
that the brightness is
stable during the
setup and
calibration!
Item Performance Action Result Notes
1 Start up instrument/
PASS.
See page 7-3 how to
set-up the instrument.
2 Prepare instrument. A. Mount the
instrument on a
stable
base.(Collimator
bench or tripod)
B. Level instrument.
3 Remove tracker unit
cover.
See page 5-3. See page 1-8 for laser
safety information.
4 Start service software. Select
Camera focusing
from
Video in
Maintenance & Service
The dialogue “Trimble
VX: Focusing video
camera” appears.
Item Performance Action Result Notes
To Next Page
