Trimble S - Base unit replacement

Chapter 5
Maintenance and Repair
Trimble S, VX, SPS & RTS Service Manual5 - 56 P/N 57150002, Revision 5.0
F
Base unit replacement
Performance
Item Performance Action Results Notes
1 Remove horizontal
turning unit.
See page 5-55.
2 Remove SRC board
incl. magnets.
See page 5-59.
3 Remove horizontal
angle disc.
See page 5-59.
4 Remove MSB board
incl. motor winding.
See page 5-62.
5 Remove FFB board
incl. Hirose
connectors.
See page 5-54.
6 Remove lid, pipe and
cable
A. Remove the four
screws.
B. Remove the lid.
C. Remove the tube.
D. Remove the cable.
See Fig. 5-54 on page 5-
57 .
