Chapter 6
Adjustment and verification
Trimble S, VX, SPS & RTS Service Manual6 - 204 P/N 57150002, Revision 5.0
F
Trimble S8 Check list after service/repair
Trimble VX Check list after service/repair
[ ] 6. Perform Vertical oscillation compensation, see page 6-25
[ ] 7. Check distances on baselines
[ ] 8. Radio range & short range test, see page 6-3.
[ ] 9. Set service interval, see page 6-201
[ ] 10. Save constants, see page 6-6
[ ] 11. Save event log, see page 4-2
[ ] 12. Clear event log, see page 4-4
[ ] 1. Remote control power test (PSM3R board mounted), see page 6-199
[ ] 2. Perform Tilt sensor offset, see page 6-29
[ ] 3. Perform HA/VA collimation, see page 6-47
[ ] 4. Perform Trunnion axis correction, see page 6-48
[ ] 5. Perform Auto focus calibration, see page 6-180
[ ] 6. Perform Tracker collimation test, see page 6-147
[ ] 7. Perform Vertical oscillation compensation, see page 6-25
[ ] 8. Check distances on baselines
[ ] 9. Radio range & short range test, see page 6-3. When performing the test
start up the instrument in Survey mode, see page 3-59.
[ ] 10. Set service interval, see page 6-201
[ ] 11. Save constants, see page 6-6
[ ] 12. Save event log, see page 4-2
[ ] 13. Clear event log, see page 4-4
[ ] 1. Perform Tilt sensor offset, see page 6-29
[ ] 2. Perform HA/VA collimation, see page 6-47
[ ] 3. Perform Trunnion axis correction, see page 6-48
[ ] 4. Perform Auto focus calibration, see page 6-180
[ ] 5. Perform Tracker collimation test, see page 6-147
[ ] 6. Perform Vertical oscillation compensation, see page 6-25
