Trimble S User Manual

Chapter 3
Theory of Operation
P/N 57150002, Revision 5.0 3 - 29 Trimble S, VX, SPS & RTS Service Manual
F
Face 2 panel compatibility
Function description optical plummet
Fig. 3-29 Optical plummet
The optical plummet is used to position the instrument above a point.
Face2 display functionality
See page 3-59 for information about the face2 display functions when starting up the instrument.
Service
Maintenance
Alignment of optical plummet.
Replacement of spare parts
• Face 2 panel complete
• Optical plummet
Face 2 panel label Variable in PASS Firmware compatibility
C00/01 0 All firmware versions
C00/02 01 1  R2.1.0
02 2  R2.1.0
03 3 or higher - RoHS  R2.1.0
