Chapter 2
General Product Information
P/N 57150002, Revision 5.0 2 - 17 Trimble S, VX, SPS & RTS Service Manual
F
Model definition
The Trimble S3/ S6/S8/VX/SPS/RTS instruments has different functions and specifications but from
a service point the instrument has many common service operations.
The alidade is the base for all instruments, same as for Trimble S3/S6/S8/VX/SPS and RTS.
The centre unit can differs between models.
Centre unit- Distance unit
The Trimble S6 High Precision / Trimble S8 / Trimble RTS 555 DR Standard / Trimble RTS 655 DR
Standard and Trimble SPS610 DR Standard distance units has different specifications but uses the
same hardware and same service operations.
