Trimble S - Transmitter and receiver fibre adjustment - Collimator 79592001 & GDM collimator T71601480

Chapter 6
Adjustment and verification
Trimble S, VX, SPS & RTS Service Manual6 - 90 P/N 57150002, Revision 5.0
F
Tools and equipment
Transmitter and receiver fibre adjustment - Collimator 79592001 & GDM collimator
T71601480
The transmitter fibre is focused from factory. Also spare parts are delivered focused. Only alignment
of transmitter fibre is necessary. Receiver fibre is focused and aligned at service.
Description Part number
Collimator bench with CCD camera - 79592001
Illumination RX S6/5600 79773001
Adapter RX S6 EDM High Precision 79559001
Adapter ring Eyepiece illumination S6 EDM High Precision 79561001
Eyepiece illumination DR 7027229001975
Adapter S6 EDM High Precision 79554001
Screen attachment DR 7027229001974
Scattered light device DR 7027229001979
GDM Collimator - T71601480
Attenuator Greyfilter TX for GDM collimator (T71601480) 59017001
Instrument holder for GDM collimator (T71601480) 59000026
Reticle illumination tool 79706001
Illumination RX S6/5600 79773001
Adapter ring Eyepiece illumination S6 EDM High Precision 79561001
Eyepiece illumination DR 7027229001975
Adapter S6 EDM High Precision 79554001
Screen attachment DR 7027229001974
Scattered light device DR 7027229001979
Other tools
Light cover front lens 79556001
Light trap 79700001
Torque wrench, 120 Ncm T71600280
Torx T8 bit Local tool
Hexagon screw driver 0,7, 0,9, 1,3 & 1,5mm Local tool
Angled hex driver without handle 0,9, 1,3 & 1,5 mm Local tool
Tweezers Local tool
Frequency counter 0,1 Hz resolution (PM6685/411 Fluke or similar) local equipment
