Chapter 3
Theory of Operation
P/N 57150002, Revision 5.0 3 - 7 Trimble S, VX, SPS & RTS Service Manual
F
Removable handle
The handle is the carrying part of the instrument. The handle can be removed.
Location of handle
Fig. 3-6 Handle location
Function description
To remove the handle loosen the two screws and pull off the handle.
There are two types of locking screws for the handle, one larger which is easier to unlock. To mount
the larger screws in the handle see page 5-8.
Service
Replacement of spare parts
• Handle complete
• Yellow and black plastic parts
Handle
