Trimble S - Tracklight; Tracklight replacement

Chapter 5
Maintenance and Repair
P/N 57150002, Revision 5.0 5 - 113 Trimble S, VX, SPS & RTS Service Manual
F
Tracklight
• Tracklight replacement
Tools and equipment
Tracklight replacement
Performance
Description Part number
Torque wrench 30Ncm T71600279
Torx T6 & T8 bit Local tools
Straight point Tweezers Local tool
Item Performance Action Result Notes
1 Remove tracker unit
cover.
see page 5-6. For laser safety
information, see
page 1-8
2 Remove tracker
transmitter board,
OTC and OTA board.
A. Remove the screw.
B. Lift up and remove the
tracker transmitter
board and spacer.
C. Remove the screw and
the o-ring.
D. Lift up and remove the
OTC board.
E. Remove the screw and
the two hex bolts.
F. Remove the shielding
covers, disconnect the
cable and remove OTA
board.
Watch the spacer.
