Chapter 6
Adjustment and verification
Trimble S, VX, SPS & RTS Service Manual6 - 52 P/N 57150002, Revision 5.0
F
Fig. 6-43 Grey filter attachment and external voltage supply
3 Mount tools. A. Mount the Eyepiece il-
lumination DR with
adapter on the eyepiece.
B. Mount the Screen
attachment with
adapter on the front
lens.
After switch
ON, the shadow
of the central
mirror can be
seen on the
screen.
Item Performance Description Result Notes
C
Cable to power supply 5 VDC
