Chapter 5
Maintenance and Repair
P/N 57150002, Revision 5.0 5 - 73 Trimble S, VX, SPS & RTS Service Manual
F
Fig. 5-68 Cable attachment
4 Remove greywedge
assembly.
Version 1 (glued in
older units)
A. Remove the locking
glue.
B. Release the screws.
C. Loosen the clamp
screw.
D. Lift up and remove
the greywedge
assembly.
See Fig. 5-69 on page 5-
73 and Fig. 5-70 on
page 5-74.
The function of the
clamping screws is to
avoid the motor
against turning.
Fig. 5-69 Removal of the locking glue
Item Performance Action Result Notes
A
B
C
D
E
F
A
