Chapter 1
General Information and safety
Trimble S, VX, SPS & RTS Service Manual1 - 18
P/N 57150002, Revision 5.0
F
Fig. 1-20 Trimble S8 DR PLUS / VX DR PLUS
Fig. 1-21 Trimble SPS DR PLUS / RTS DR PLUS
The laser pointer warning label,
see Fig. 1-18 on page 1-16
is located on top of the distance unit
cover.
Distance
measurement
trac
ker
and
laser
pointer
aper
ture
Camera
aper
ture
Distance
measurement
tracker
and
laser
pointer
aperture
T
racklight
aperture
27
29
