Chapter 5
Maintenance and Repair
P/N 57150002, Revision 5.0
5 - 117
Trimble S, VX, SPS & RTS Service Manual
F
Fig. 5-112 Tracker unit boards and SCF board
4
Remove SFC board.
A.
Disconnect all cables
from the SFC board.
B.
Remove the two
screws.
C.
Remove the SFC
board,
see Fig. 5-113
on page 5-118
.
Item
Performance
Action
Result
Notes
A
B
C
D
E
F
2.21
lbfin
2.21
lbfin
2.21
lbfin
25
Ncm
/
25
Ncm
/
25
Ncm
/
302
304
