Chapter 6
Adjustment and verification
P/N 57150002, Revision 5.0 6 - 77 Trimble S, VX, SPS & RTS Service Manual
F
Fig. 6-84 Reference signal test
5 Exit
APD / Reference
fibre
software.
A. The software MUST
be terminated by
clicking the
EXIT
button.
B. If no adjustments of
reference fibre should
be made, click
Yes
otherwise click No to
adjust.
C. Click
OK button,
instrument will exit
service mode and be
restarted.
Fig. 6-85 Reference fibre check, exit info
