10 Check High Power
Laser pointer
alignment to a white
target at a distance
between 50-150
meter.
Aim laser spot to a white
target in 50-150 m under
dark light conditions.
Horizontal:
+/-10mm,
Vertical: 36mm
+/-10mm
Item Performance Description Result Notes
