Trimble S User Manual

Chapter 8
Replacement Parts & Tooling
P/N 57150002, Revision 5.0 8 - 11 Trimble S, VX, SPS & RTS Service Manual
F
9 Package spring flat side cover, 5p See item 7 1
10 Package spring flat side cover short, 5p See item 7 1
11 Side cover radio incl. antenna complete - RoHS 59123019 1
11 Side cover radio dark grey complete 59123011 1
11 Side cover radio SPS/RTS incl. antenna complete 59123012 1
12 Antenna 59000398 1
13 Package washer plain 3,1 x 1 x 0,5 - PA, 20p 59568001 3
14 Package screw M3 x 20 A2-70, 20p 59000174 3
15 Package spring compression, 5p 59000089 1
16 Package snap lock for batt. cover, 5p 59120001 1
17 Cover battery 59119001 1
Item Description Part number Qty
