Trimble S User Manual

Chapter 8
Replacement Parts & Tooling
P/N 57150002, Revision 5.0 8 - 21 Trimble S, VX, SPS & RTS Service Manual
F
6 Package washer 2,7 A2 - 70, 20p 79000241 3
7 Package adjustment EDM base screw M3 x 12, 20p 79000076 4
8 Package cable SFC - EDM, 5p 79593001 1
9 Package EDM base screw, 20p 79000320 1
10 Frame unit EDM High Precision 79897001 1
10 Frame unit EDM DR 59081025 1
11 Greywedge motor R71610004 1
12 Transceiver PCA - RoHS 79724019 1
12 Board Tranceiver EDM DR 59112025 1
13 Package screw sts 2,5 x 8 A2-70, 20p 79000261 2
14 Package Coax cable 65mm, 5p 79876001 1
14 Package coax cable 250mm (5p) 59079025 1
15 Receiver fibre 79809001 1
15 Receiver fibre DR 59080025 1
