Chapter 8
Replacement Parts & Tooling
P/N 57150002, Revision 5.0
8 - 45
Trimble S, VX, SPS & RTS Service Manual
F
60
Grease BEM 34-32
55000311
61
Isoflex 3000 (grease)
R71905945
62
Glue MS 1855 (previously pliobond)
R95100159
Item
Description
Part number
592
594
