Boundary Scan Test Interface
Élan™SC520 Microcontroller User’s Manual 25-9
REQ1 Input 238
REQ0
Input 239
Control 240
GNT4
Output 241
Control 242
GNT3
Output 243
Control 244
GNT2
Output 245
Control 246
GNT1
Output 247
Control 248
GNT0
Output 249
Control 250
GPA25 Bidirectional 251, 252
GPA24 Bidirectional 253, 254
GPA23 Bidirectional 255, 256
GPA22 Bidirectional 257, 258
GPA21 Bidirectional 259, 260
GPA20 Bidirectional 261, 262
GPA19 Bidirectional 263, 264
GPA18 Bidirectional 265, 266
GPA17 Bidirectional 267, 268
GPA16 Bidirectional 269, 270
GPA15 Bidirectional 271, 272
GPA14 Output 273
GPA13 Output 274
GPA12 Output 275
GPA11 Output 276
GPA10 Output 277
GPA9 Output 278
GPA8 Output 279
GPA7 Output 280
GPA6 Output 281
GPA5 Output 282
GPA4 Output 283
GPA3 Output 284
GPA2 Output 285
GPA1 Output 286
GPA0 Output 287
Control 288
GPD15 Bidirectional 289, 290
GPD14 Bidirectional 291, 292
Table 25-3 Main Data Scan Path (Continued)
Pad Name Scan Type Boundary Scan Order
