Boundary Scan Test Interface
25-10 Élan™SC520 Microcontroller User’s Manual
GPD13 Bidirectional 293, 294
GPD12 Bidirectional 295, 296
GPD11 Bidirectional 297, 298
GPD10 Bidirectional 299, 300
GPD9 Bidirectional 301, 302
GPD8 Bidirectional 303, 304
Control 305
GPD7 Bidirectional 306, 307
GPD6 Bidirectional 308, 309
GPD5 Bidirectional 310, 311
GPD4 Bidirectional 312, 313
GPD3 Bidirectional 314, 315
GPD2 Bidirectional 316, 317
GPD1 Bidirectional 318, 319
GPD0 Bidirectional 320, 321
Control 322
GPRESET Output 323
Control 324
GPIORD
Output 325
Control 326
GPIOWR
Output 327
Control 328
GPMEMRD
Output 329
Control 330
GPMEMWR
Output 331
Control 332
PIO27 Bidirectional 333, 334
Control 335
PIO26 Bidirectional 336, 337
Control 338
PIO25 Bidirectional 339, 340
Control 341
PIO24 Bidirectional 342, 343
Control 344
PIO23 Bidirectional 345, 346
Control 347
PIO22 Bidirectional 348, 349
Control 350
PIO21 Bidirectional 351, 352
Control 353
PIO20 Bidirectional 354, 355
Control 356
Table 25-3 Main Data Scan Path (Continued)
Pad Name Scan Type Boundary Scan Order
