7.2.9 M Mode Depth
The function is the same as 2D mode depth '2D Mode Depth'
on page 6-4
7.2.10 M Cineloop
Several 2D image frames and M mode trace information can be recalled. When freezing, a
certain time frame (M information of the last examination sequence) is stored in the loop
memory. The sequence can be reviewed second by second.
Display: Cine for 2D imagesor Loop for M trace on the monitor (status bar) min length: 60
seconds
1. Freeze the image.
After freezing, the trackball is active for the M mode trace loop / 2D cine.
2. The upper trackball key changes from the M loop to the 2D cine, and back. The active
cine is displayed on the monitor: 2D/M-image or 2D/M-image
3. Use the trackball to scroll through the stored sequence. The motion line will scroll
simultaneously with the 2D image.
The current indicated through the green arrows on the motionline.
7.3 M Sub Menu
The M Main menu has to be active.
Select the control [S Sub]. The M Submenu appears.
M Mode
7-6
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
