falling edge: 12 steps
Gain control: +15dB to -15dB, 0.2dB steps
PD Ensemble: 7 to 31
PD Line Density: 10 steps
Pulse repetition frequency: 150 Hz to 20.5 kHz
PD Map: 8 different color codes for each probe
Frequency range: 1 to 16 MHz depending on the probe, adjustable in 3 steps (low, mid, high)
Flow Resolution: 4 steps (low, mid1, mid2, high)
Balance: from 25 to 225 in 41 steps
Artefact suppression: yes
16.10.6 HD-Flow Mode (HDF):
Screen formats: 2D+HDF (single, dual, quad)
Display Modes Simultaneous dual mode: 2D/2D+HDF
Triplex mode: 2D+HDF/PW; 2D/M+MHDF
Volumen Mode: 3D+HDF
HD-Flow Coding Steps: 256 color steps
HD-Flow window size: lateral: maximal to minimal B mode scan angle
axial: B-scan range
Display mode: P (power)
Wall Motion Filter: 8 steps (low1, low2, mid1, mid2, high1, high2, max1, max2)
Smoothing Filter: 12 steps rising edge;12 steps falling edge;
Gain Control: +15dB to -15dB, 0.2dB steps
HD-Flow Ensemble: 7 to 31
HD-Flow Line Density: 10 steps
Pulse Repetition
Frequency.
150Hz to 20.5KHz
HD-Flow Map: 8 different color codes for each probe
Frequency Range: 1 to 16 MHz depending on the probeadjustable in three steps (low, mid, high)
Flow Resolution: 4 steps (low, mid1, mid2, high)
Balance: from 25 to 225
Artefact suppression: yes
16.10.7 Tissue Doppler Mode (TD)
Screen formats: 2D+TD (single, dual, quad)
Display modes: Simultaneous dual mode: 2D/2D+TD
Triplex mode: 2D+TD/PW, 2D/M+MTD
Technical Data / Information
16-20
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
