GE Voluson S8 - 16.10.8 Volume Scan Module

TD coding steps: 65536 color steps
Depth range: axial: 0 to B-scan range
lateral: 0 to B-scan-range
Zero line shift: 17 steps
Inversion of color direction: yes
Smoothing Filter: 12 steps rising time
12 steps falling time
Gain control: +15dB to -15dB, 0.2dB steps
Line Density (color line
density):
10 steps
Ensemble (color shots per
line):
3 to 31
Flow Resolution: 4 steps (low, mid1, mid2, high)
Pulse repetition frequency: 150 Hz to 20.5 kHz
TD Map: 4 different TD Map
Frequency range: 1 to 16 MHz depending on the probe,adjustable in 3 steps (low, mid, high)
Balance: from 25 to 225
Max. meas. velocity: 4.23 m/sec
Min. meas. velocity: 0.3 cm/sec
Display Mode: V (velocity)
Scale: kHz, cm/s, m/s
16.10.8 Volume Scan Module
Vol. scan size: max. 64 MB for gray volumes
max. 90 MB for color volumes
The required memory space depends on scan parameters (VOL-box size and
quality (low , mid1 , mid2 , high1 , high2 , max). typical:0.8-5 MB
Lines/2D-image: max. 1024 (typ. 80 to 350)
2D-images/volume: max. 4096 (dependent on acquisition mode)
VOL-Frames/sec.: max. 40 (typ. 4-8) The frame rate depends on scan parameters: VOL-Box
size, quality and probe.
4D Volume Cine: up to 128 volumes
Display of sectional plane
images:
synchronous with control setting, arbitrary movement in volume, monitored
position in volume.
Rotation: 360º, 1/3º increments (X-, Y- and Z-axis)
Magnification: adjustable from 0.3 to a factor of 4.00
Acquisition Modes: 3D Static:
3D (2D incl. CRI)
3D/PD (incl. CRI)
Technical Data / Information
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 16-21
