GE Voluson S8 - 11.2.7.4 Vascular Calculations in M Mode; 11.2.7.5 Vascular Calculations in Spectral-Doppler Mode; 11.2.7.6 Vascular - Worksheet

The measurement procedures in 2D Mode are the same than in application “Abdomen”.
Review: Abdomen Calculations in 2D Mode in
'Abdomen Calculations' on page 11-24 .
11.2.7.4 Vascular Calculations in M Mode
•
Vessel Diameter
•
Stenosis Diameter
•
Time
•
HR (Heart Rate)
•
IMT
The measurement procedures in M Mode are the same than in application “Abdomen”.
Review: Abdomen Calculations in M Mode in 'Abdomen Calculations' on page 11-24 .
11.2.7.5 Vascular Calculations in Spectral-Doppler Mode
•
Auto Trace
•
Manual Trace
•
Measurement of Each Item
•
Measurement of PS/ED RI+SD
•
Time
•
HR (Heart Rate)
The measurement procedures in Spectral Doppler Mode are the same than in application
“Abdomen”. Review: Abdomen Calculations in Spectral Doppler Mode in
'Abdomen
Calculations' on page 11-24 .
11.2.7.6 Vascular - Worksheet
Press the [Worksheet] key on the control panel to view the report that contains detailed results
of vascular calculations.
