Height: min. 975 mm (38.4 in); max. 1725 mm (67.9 in)adjustable with electrical motor
Weight: Basic system (without accessories) approx. 90 kg
16.2.2 Power Supply
Power
requirements:
220V - 240VAC; 100V - 120 V AC
Frequenzy: 50 Hz, 60 Hz (± 2%)
Power
consumption:
nominal 900VA including all optionsTypical power consumption with 500VA load
approx. 1.75A at 230V/50Hz without peipherals
Thermal output: 1200 BTU/h
Fan: Perceived noise level: max. 40 dB/A
16.2.3 AC Power Cord Set
Power cord: Type SJT, SJE, SJO or SJTO, 14AWG, 3-Conductor,VW-1, 125 V or 250 V, 10 A,
max 3.0 m long;
One end with Hospital Grade Type, NEMA 5-15P or 6-15P. Other end with appliance
coupler.
"CAUTION Grounding reliability can only be achieved when the equipment is
connected to an equipment receptacle marked "Hospital Only" or "Hospital Grade"".
16.2.4 Keyboard
Floating keyboard: adjustable in height:
Rotation: adjustable +/- 30˚ from center
Alphanumeric
keyboard:
Backlit
Hard key buttons: Ergonomic layout, Interactive Back-lightning
Recording keys: Integrated for remote control up to 4 peripherals of DICOM devices, one dedicated
DVD recording key
16.2.5 Console Design
Probe ports: 4 ports: 3 active ports; 1 none active port; 1 CW port
Probe connection are designed to allow free movement of legs
Probe holder: 4 + 2 optional (two dedicated for trans vaginal probes, vertically and horizontally)
Gel holder: 1
Hard disk: Integrated HDD (160 GB)
DVD: Integrated DVD +/- R(W) / CD-R(W) drive
Peripherals: On-board storage for peripherals: black/white printer, color printer.
Wheels: Wheel diameter 125 mm, integrated locking mechanism that provides rolling lock.
Handles: Front and rear handles
Technical Data / Information
16-4
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
