GE Voluson S8 - 16.12.2 Connectivity behind rear panel (accessible after opening); 16.12.3 Peripherals; 16.12.4 Drives; 16.12.5 ECG Module

16.12.2 Connectivity behind rear panel (accessible after opening)
DVI-D out: 1x DVI-D for OUT
Resolution: SXGA
Audio out L/R: Cinch, LF-signal 1.2Vss
Cinch, RF-signal 1.2Vss
USB (1x):
RS 232. optional (via USB to RS232 converter)
16.12.3 Peripherals
Remote BW Printer: via USB
Remote Color Printer: via USB
Footswitch: via USB
16.12.4 Drives
DVD/CD + (R)W
Drive:
Read Speed: 16x DVD-ROM
48x CD-ROM
Write Speed: DVD+R: 24x
DVD+RW: 8x
CD-R: 48x
CD-RW: 32x
Supported Media: DVD-ROM, DVD+R, DVD+RW, CD-ROM, CD-R, CD-RW
16.12.5 ECG Module
Input Dynamic range: ±5mV
Sample rate: 600s/s
Bandwidth: 0.05 to 150Hz.
Size: 30 - 300 beats per min.
Rejection filter: 80X50X15mm
Dimensions (L/W/H) 220/150/40 mm
Symbols used:
Insulated patient application part (Type CF)
ECG symbol
Technical Data / Information
16-30
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
