High PRF Doppler Mode
Color Flow Doppler Mode(CFM)
CW Doppler Mode(CW)
Power Doppler Mode (PD)
HD-Flow Doppler Mode (HD-Flow)
Tissue Doppler Mode (TD)
B Flow Mode (BF)
Elastography mode
XTD-Mode
Contrast Agent Mode (Contrast)
M-Color Flow Modes (M/CF, M/HD-Flow, M/TD)
Volume Modes (3D/4D):
3D Static
4D Real Time
VCI-A
VCI OmniView
STIC
4D Biopsy
16.4 Screen Formats
2D Imagine: Single (2D*)
Dual (2D*+2D*)
Quad (2D*+2D*+2D*)
*2D = B, B-Flow, Contrast, B/CF, B/PD, B/HD-Flow, B/TD
TL Imaging: B+TL* (Top/Bottom): 3 format sizes: 40/60, 50/50, 60/40
B+TL** (Side/Side): 50% / 50%
B+AMM+AMM (Side/Top/Bottom): 50/25/25%
*TL = M, AMM, PW
**TL = M, AMM, PW, CW, M/CF, AMM/CF
3D/4D Imaging. Render: quad (A/B/C/3D, dual (A/3D), single(3D)
Sect. Planes:quad (A/B/C), dual (A/B, A/C), single (Ref)
TUI: 1x1, 1x2, 2x2, 3x2, 3x3, 3x4, 4x4
Segmentation: quad (A/B/C/Segm. Object), single (Segm. Object)
Technical Data / Information
16-6
