Init condition of an endocavity probe: If the VOL-start image is a median-sagittal section
(left side of the screen is posterior), the following Init
positions are obtained:
The sectional image A represents that 2D image
visible in the Vol preparation area.
A - anterior (ventral) ; P - posterior (dorsal) Cr -
cranial ; Ca - caudal ; R - right ; L - left
9.2.4.4 Initial Condition of different Probes
Select this key on the menu area to reset the rotations and translations of a volume section to
the initial (start) position.
Initial condition of an endorectal probe:
Volume Mode
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 9-33
