3D4D Probe
Applications
Exten
ded
View
Tissue
Doppl
er
MCF
M )
(MCol
or
Flow
Mode)
HD-
Flow
Color
STIC
STIC
CFPD
VCI HPRF
Biops
y
Elasto
graph
y
RAB4-8-RS X X X X X X X X X -
RIC5-9W-RS X X X X X X X X X X
RAB2-5-RS X X X X X X X X X -
5.1.4 Settings
Probe Designation
Center Frequency
[MHz]
Doppler Frequency[MHz]
Depth[cm
]
2D Angle
[Degree] (/
wide
phased)
High Mid Low max. max.
RAB2-5-RS 3.2 (2.2~4.1) 3.22 2.95 2.38 30 80
RAB4-8-RS 4.4 (4.0~4.8) 4.00 3.45 3.03 26 70
E8C-RS 6.5 (4.6~8.0) 6.67 5.88 4.76 16 123 / 161
C1-5-RS* 3.4 (2.2~4.7) 3.23 2.86 2.13 30 69
4C-RS 3.1 (2.0~3.9) 3.23 2.70 2.27 30 58
AB2-7-RS 4.3 (3.9~4.8) 4.17 3.33 2.63 28 80
12L-RS 7.7 (5.4~10.0) 7.14 6.25 5.26 11 -
9L-RS 5.3 (3.5~7.0) 5.27 4.55 3.71 14 -
RIC5-9W-RS 6.6 (5.1~8.3) 6.25 5.56 5.00 16 146 / 179
3Sc-RS 2.8 (1.8~3.7) 2.50 2.17 1.85 24 90
ML6-15-RS* 9.0 (6.0~11.5) 9.10 7.70 6.26 12 -
8C-RS 6.5 (4.6~8.0) 6.67 5.88 4.76 16 132
P2D 2.0 - - - - -
5.1.5 Probe introduction
The Voluson® S6/S8 supports four types of probes:
•
Curved Array (Convex): Curved Array (convex) probes are usually designated by the
prefix "A"; the endocavity probe is designated by the prefix "I".
•
Linear Array: Linear Array probes are designated by the prefix "S".
•
Phased Array (Sector): Phased Array Sector probes are designated by the prefix "P".
•
Continuous Wave Doppler: Continuous Wave Doppler probes are designated by the
suffix "CW".
•
Real Time 4D: Real Time 4D Probes are designated by the prefix “R”.
Probes and Biopsies
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 5-5
