Main group 1: Main menu keys for:
•
Presets
•
Sub window probe dependent functions
•
Image up/down
•
Image left/right
•
Virtual Convex mode
•
FFC (Focus and Frequency Composite)
•
XBeam CRI (CrossBeam Compound Resolution Imaging) CE (Coded
Excitation)
•
SRI (Speckle Reduction Imaging)
•
Image Angle
•
β-View (Beta View)
•
Focal ZonesOTI (Optimized Tissue Imaging)
•
Frequency
Main group 2: Sub menu keys for:
adjusting the 2D image
Main group 3: Menu Utilities keys for:
•
System Setup
•
Biopsy
•
Histogram
•
etc.
Main group 4: Change from write-only functions to read-only functions when changing
read/write (Freeze/Scan):
Remarks:
Selecting a new mode displays a new “Main” menu with the operating functions of this mode.
The keys for the functions Focus, OTI,
β-View, Frequency, Angle, Virtual Convex mode, FFC,
CE, XBeam CRI and SRI only appear on the menu area if they are available for the selected
probe.
3.5.2 Changing of Menus
Each menu has its own menu key with a “topic” name. By selecting the menu key the referring
menu appears on the menu area. The keys for the different sub-menus can be found next to
the “Main” menu key on the menu area.
Remark: If no probe is selected, the “PROBE/PROGRAM” menu is displayed.
Description of the System
3-8
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
