GE Voluson S8 - 9.3.5 3 D Gray Chroma Map; 9.3.6 Contrast; 9.3.7 Background; 9.3.8 Balance

9.3.5 3D Gray Chroma Map
1. Select the [Gray 3D] key.
2. Select either a predefined Gray Curve (1-18).
Note
These settings require an alert observation of the influence on the 3D image!
3. With the Background function, the contrast between screen background and 2D image is
set.
4. This function is only of significance in B scan, when a part of the screen background is
visible.
5. Adjust the contrast of the screen background from dark to bright.
Return to the 3D/4D Menu.
9.3.6 Contrast
To adjust the contrast of the 3D/4D image: '3D Gray Chroma Map'
on page 9-47
Note The settings require an alert observation of the influence on the 3D image! These keys are not
available in Static 3D Sectional Planes mode.
9.3.7 Background
To adjust the background: '3D Gray Chroma Map'
on page 9-47
Note This key is not available in Static 3D Sectional Planes mode.
9.3.8 Balance
Normally this function does not need to be adjusted.
Note
This key is only available if a 3D+CFM, 3D+PD or a 3D+HD image is acquired.
Volume Mode
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 9-47
