11.2.4.29 Summary Report - Exam Comment
Select this key to enter a comment using the keyboard, or to enter a previous defined
comment by selecting the [Comment A], [Comment B] or [Comment C] key. For further details
review: Exam Comment
(chapter
'Basic Patient Worksheet Functions'
on page 11-101
)
.
The “Summary Report - Exam Comment” is always included in the report printout. For further
details review: To print a Report
(chapter
'Basic Patient Worksheet Functions'
on page 11-
101
)
.
11.2.5 Cardiac Calculations
Application “Cardiology”, (Factory - Sub Category: Biometry) allows measurements/
calculations in 2D/3D mode, M mode and Spectral-Doppler mode, using various measure
items. For details about settings, review: Measure Setup - Measure & Calc
(chapter
'The
Measure Setup Pages'
on page 11-109
)
The methods for obtaining measurements in the Cardiology Calculations menu are similar to
the generic measurement functions in 2D, M and Spectral Doppler mode.
11.2.5.1 Items of Cardiology Calculations
The items of cardio calculations in each mode are as follows:
2D/3D Mode: LV Simpson (A4C Dias, A2C Dias, A4C Syst, A2C Syst), Volume A/L
(LV Vol.Dias,
LV Vol.Syst)
, LV-Mass (Epi. Area, Endo. Area, LV length), LV (IVSd, LVDd, LVPWd,
RVDd, IVSs, LVDs, LVPWs, RVDs), LVOT Diameter, RVOT Diameter, MV (Dist A,
Dist B, Area), TV (Diameter), AV/LA (Ao Root Diam, LA Diam), PV (Diameter)
C (Color) Mode: PISA
M Mode: LV (IVS, LVD, LVPW, RVD), AV/LA (Ao Root Diam, LA Diam, AV Cusp Separation,
Ao Root Ampl.), MV (D-E, E-F Slope, A-C Interval, E-EPSS, E-S Dist.), HR (Heart
Rate)
Doppler Mode: MV (Mitral Valve), AV (Aortic Valve), TV (Tricuspid Valve), PV (Pulmonary Valve),
LVOT & RVOT-Doppler (Left & Right Ventricle Outflow Tract), Pulmonic Veins, PAP
(Pulmonary Artery Pressure measurement), HR (Heart Rate)
Other
measurements &
calculations:
Diast. Vol.(Bi), Syst.Vol.(Bi), Stroke Volume, Volume Flow, Cardiac Output, Ejection
Fraction, Fractional Fract. Shortening, Myocardial Thickness, LA/Ao, Ratio, E/A Peak
Gradient, Peak Gradient Acceleration, Mean Gradient, Mean Gradient Acceleration,
VTI, TVA, PG, PHT, MVA, AVA, ERO, etc.
Description of Abbreviations review:
Chapter 17
11.2.5.2 Before Starting Cardiology Calculations
Measurements and Patient Worksheets (Reports)
11-60
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
