8.1.1 PW Main Menu
[PW Mode] key (hard key)
Press the [PW] control to activate the PW mode in the preparation
mode. First only the PW-cursor appears on the active 2D image.
To start and use the PW mode: 'PW Operation'
on page 8-4
To
adjust the PW settings: 'PW Sub Menu'
on page 8-6
This hard key is also the Gain control for the PW mode in scan mode
:
'PW Operation'
on page 8-4
The “PW Main” menu appears on the menu window (scan mode).
Example: PW Main/Sub window
Example: PW rotaries
Remarks:
•
Changing the Gain, Gate width, Loudspeaker Volume, Wall Motion Filter and the PRF is
not possible in freeze mode.
Doppler Modes
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 8-3
