To use special utilities:
'Utilities'
on page 13-2
and 'Gray Map'
on page 6-22
Note
The MCF mode is available if the selected probe is capable of the MCF mode.
7.4.1 MCF Main Menu
[M Mode] key + [CF Mode] key (hard keys)
By pressing the [M] control and the [CF] control, the MCF mode is switched on in the
preparation mode. The M-cursor with M-Color window appears on the active 2D image.
These hard keys are also the Gain control for the MCF mode (only in scan mode): 'M Gain
Control'
on page 7-4
To start and use the MCF mode: 'MCF Operation'
on page 7-10
To adjust the MCF
settings: 'MCF Sub Menu'
on page 7-11
The “MCF Main” menu appears on the menu area. (scan mode)
M Mode
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 7-9
