3.5.3.1 Detailed Image information
Image Info: B (2D) Mode
User program Name of user program
7.5-5.0 Receiver frequency [MHz]
85 Acoustic power [%] or fixed to maximum power 100%
Gn -12 Gain [dB]
C5 / M7* Dynamic curve [number] and Gray map [number]*
P6 / E4 Persistence [number] and Edge enhancement [number]
Image Info: M Mode
Gn 10 Gain [dB]
C1 selected Dynamic curve [number]
E1 Edge enhancement [number]
Rej 10 Reject [number]
Image Info D (PW, CW) Mode
85 Acoustic power [%] or fixed to maximum power 100%
Gn 10 Gain [dB]
WMF 230 Hz Wall motion filter [Hz]
SV Angle 60˚ Angle correction
Size 2.0 mm Sample volume size
Depth 21.2 mm Sample volume depth
Frq mid Transmit frequency [Probe data]
PRF 1.2 kHz Velocity Range [kHz, cm/s, m/s]
Image Info: CF-Mode, PD-Mode, HD-Flow Mode
85 Acoustic power [%] or fixed to maximum power 100%
Gn 5.6 Gain [dB]
Frq mid Transmit frequency [Probe data]
Qual mid Quality of CF [table]
WMF mid Wall motion filter [table]
PRF 1.2 kHz Velocity Range [kHz, cm/s, m/s]
Image Info: 3D/4D Mode
User program Name of 3D/4D user program
Th26 / Qual high1 Threshold [number] and Quality [table]
B68˚ / V55˚ Angle of the Volume Box [degree] and Volume Angle [degree]
Mix 16/84 Mix between selected render modes [percent]
S.txt / S.sm selected render modes
M14 / 100 Gray Map Position [number] and Contrast [number]
Mode selected Acquisition Mode
Description of the System
3-10
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
