Line Density steps (pre) low, norm, high
Reject: 51 steps (pre) from0 to 225
Enhance: 6 steps (pre) 0 to 5
Gray maps: 18
Tint maps: 15
Dynamic: 12 different dynamic curves C1-C12
Display modes: B, XTD
Screen formats: 2D imaging: Single (B), Dual (B+B), Quad (B+B+B) XTD View: Single (XTD),
Dual (B+XTD)
16.10.2 M-Mode
Working modes: M (conventional M-Mode) / AMM (Anatomical M-Mode)
Power control range: 1 - 100%
GAIN range: +15 to -15 dB
M sweep speeds: 900 / 450 / 300 / 225 / 150 / 100 pixels/sec;
26,44 / 13.22 / 8.81 / 6.61 / 4.40 / 2.94 cm/s in relation to system monitor
Review (memory times): > 60 s (32MB)
Signal processing M: Dynamic range: 1 to 12
Reject: 0 to 255
Enhance: 0 to 5
Gray maps: 18
Tint maps: 15
Display Modes: M: 2D+M, 2D+M/CF, 2D+M/HD-Flow, 2D+M/TD
AMM: 2D+AMM, 2D/CF+AMM/CF, 2D/HD-Flow+AMM/HD-Flow, 2D/TD
+AMM/TD
Screen formats: 2D+M and 2D+AMM: up/down (horizontal): three different sub formats 40/60,
50/50, 60/40%; left/right (vertical): 50/50%
(window arrangement) 2D+AMM+AMM: left//rt-up/rt-down: 50//25/25%
16.10.3 Spectral-Doppler PW/CW
Operating Modes: Pulsed Wave Doppler (Single Gate), PW
Continuous Wave Doppler, CW
Transmit frequencies: PW-Doppler: 1.75-16 MHz
CW-Doppler: 1.75-16 MHz
Pulse Repetition
Frequency (PRF):
PW-Doppler: 0.9 - 22.0 kHz
CW-Doppler: 1.3 - 41.7 kHz
Sample Volume Length: 0.7, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15 mm
(Doppler Gate): Position: 5 mm to B-scan end
Technical Data / Information
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 16-17
