Init condition of an abdominal probe: If the VOL-start image is a longitudinal section (Cr
on the left of the screen below), the following Init
positions are obtained:
The sectional image A represents that 2D image
visible in the Vol preparation area.
A - anterior (ventral) ; P - posterior (dorsal) Cr -
cranial ; Ca - caudal ; R - right ; L - left
Volume Mode
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4 9-31
