Auto/Manual Trace: Select the Doppler measuring results, which
should be displayed after each Auto Trace,
Manual Trace and Real Time Trace
measurement.
Calculation - Ratio: Select either: Off or On If Ratio is “On” (check
mark visible), select the desired ratio
calculations that should be displayed in the
Patient worklist. (Either select the ratios
individual or set only one check mark directly
into the “black” box to mark them all.)
OB Table: Select either: Off or On If OB Table is “On”
(check mark visible), select the desired tables
that should be displayed in the Patient worklist.
(Either select the tables individual or set only
one check mark directly into the “black” box to
mark them all.)
Calculate Z-scores based on: Check the appropriate checkmarks (BPD, FL,
GA)
Sono AVC: Graph: The Sono AVC graphs can be edited im
millimeters or in cubic centimeters.
Data: Check DICOM SR
if Sono AVC data has to be sent via DICOM
Cut-off follicles: Defines the follicle cut-off range for SonoAVC.
Follicles are seperated in SonoAVC and in the
report.
Data Transfer: Choose between Voluson format of DICOM SR.
Datas will be sent in the chosen format.
Sono NT defaults:
Default Tool Distance Default NT measurement tool
Note: If “SonoNT” is not available:
1. “Distance” radio button must be
selected.
2. The whole “Default Tool” must be
disabled.
SonoNTii
SonoNTim
Change Control: I <> I Yes/No Enable or hide the algorithm switch on
the touch panel. Switch between i-i or im.
Magnification Warning On/Off Enable display size warning.
Clear SonoNT Graphics On/Off If the checkbox is ticked, the SonoNT
ROI and NT border will be cleared after
the SonoNT measurement has been
accepted.
Measurements and Patient Worksheets (Reports)
11-126
Voluson® S6/S8 Basic User Manual
5433669-100 Revision 4
