Fix Caliper by Print key: Select if the last measurement caliper of the currently performed
measurement should also be fixed automatically, when
•
you press the [Freeze] key
•
you press the [Print A] or [Print B] key
•
you press the [Save] key
•
you press the [ABC] , [Bodymark] or [Indicator] key
Note: More than one selections are possible.
Cursor size: Select the size of the measurement cursor (small or large).
Color when set: Select the color of a fixed measurement cursor.
Cursor line display: Select if the cursor line is displayed (= Yes), or if only the cursor
number is displayed (= No) after completing a measurement.
Ellipse cross line display: Select Yes or No
Cursor Position: Select Last or Image center
Cursor Type: Select Number, Label or Number & Label
Font Size: Select the font size used in the resulting window (small, medium,
large)
Font Color: Select the font color used in the resulting window
Result Position: Select the measurement result location on the monitor display.
Result Position Mode
dependent:
If desired, set the check mark and then adjust the measurement
result location on the monitor display:
Result Position 2D Choose the position from the pulldown menu.
Result Position M Choose the position from the pulldown menu.
Result Position of Doppler Choose the position from the pulldown menu.
