2 Downloading
23-12 SmartAXIS Touch User's Manual
5 Click Download.
• When Communicate with is set to Touch and Port to USB, the project data starts downloading.
• When Communicate with is set to Touch and Port to Ethernet, the Target IP Address dialog box is displayed.
Specify the IP address of the Touch, and then click OK to start the download. For details, refer to “To download
project data” on page 23-7.
• When Communicate with is set to O/I Link Slave, the Target Slave dialog box is displayed. Specify the slave
station of the Touch to download to, then click OK to start the download.
If Port is set to Ethernet, specify the IP address of the O/I Link Master via which to download. For details, refer to
“To download project data” on page 23-8.
6 Click Yes.
The Download Project dialog box is displayed and the project file starts downloading.
When finished downloading, a completion message is displayed.
7 Click OK.
8 Click Close on the Download Project dialog box.
This concludes downloading project data.
If security is enabled in the Touch project, the Password Screen is displayed. Enter the password.
For details, refer to Chapter 21 “User Accounts and the Security Function” on page 21-1.
• Do not turn off the Touch while project data is downloading.
• If project data downloading fails and communication is not possible, turn the Touch off and on, then
download the data once again.
• During communication with an O/I Link Slave using the online function, O/I Link Master operation is
stopped.
For details on writing project data to an external memory inserted in the computer, refer to Chapter 26
“Downloading” on page 26-6.
