2 Downloading
23-14 SmartAXIS Touch User's Manual
■ Download Recipe Files to External Memory
Select this check box to create a RECIPE folder or recipe files in an External Memory Folder on an external memory
inserted in the Touch when downloading projects. Only on channels for which Save to in the Recipe Settings dialog
box is set to External Memory, and Recipe Function is set to Use.
• When Download Data is set to All, recipe files are created for all channels for which recipe data is set.
• When Download Data is set to Modified Data Only, only recipe files on channels where recipe data has
changed are created.
• When Download Data is set to Select Files, no recipe file is created.
■ Download
• When Communicate with is set to Touch and Port to USB, the project data starts downloading.
• When Communicate with is set to Touch and Port is set to Ethernet, the Target IP Address dialog box is
displayed. Specify the IP address of the Touch, and then click OK to start the download. For details, refer to “To
download project data” on page 23-7.
• When Communicate with is set to O/I Link Slave, the Target Slave dialog box is displayed. Specify the slave
station of the Touch to download to, then click OK to start the download.
If Port is set to Ethernet, specify the IP address of the master via which to download. For details, refer to “To
download project data” on page 23-8.
• When Communicate with is set to External Memory, the Select Drive dialog box is displayed. Select the
external memory drive, then click OK to start the download. For details, refer to “2.3 Downloading Files to an
External Memory Inserted in the Touch” on page 23-16.
■ Cancel
Stops downloading of project data.
• Do not turn off the Touch while project data is downloading.
• If project data downloading fails and communication is not possible, turn the Touch off and on then
download the data once again.
• During communication with an O/I Link Slave using the online function, O/I Link Master operation is
stopped.
