iPECS UCP
Feature Description and Operation Manual Issue 1.3
102
2.35 Door Open
Description
The iPECS UCP modules are equipped with relays that activate External Control Contacts.
The contacts can be assigned to one of several functions including a Door Open Contact.
When used as a Door Open Contact, the contact is connected to a door-lock release
mechanism. When assigned stations receive the Door Bell signal, the user may dial the Door
Open code to activate the contact.
iPECS IP and LDP Phones may be assigned a Flex button as a {DOOR OPEN} button.
Operation
iPECS IP & LDP Phones
[TRANS/PGM] + {FLEX} + Door Open code (“#*1” or “#*2”) + [HOLD/SAVE]
To assign a {DOOR OPEN} button
1. Lift the handset or press the[SPEAKER] button.
To activate the relay contact
2. Dial the Door Open code, “#*1” in UCP100 or “#*1”to “#*4” in UCP600 and
UCP2400.
3. Hang-up to return to idle.
Or,
1. Lift the handset or press the[SPEAKER].
2. Press the {DOOR OPEN} button.
3. Hang-up to return to idle.
Conditions
1. The UCP100 has a single External Control Contact while the UCP600 and
UCP2400 each have four (4) External Control Contacts. Please refer to the iPECS
UCP Hardware Description and Installation Manual for installation directions.
2. The Door Open feature dial code is based on the assigned External Contact as
below:
External Contact 1 = “#*1”
External Contact 2 = “#*2”
External Contact 3 = “#*3”
External Contact 4 = “#*4”
3. The contacts are rated at 1 amp, 24 VDC.
4. A station will receive error tone if not allowed access to the Door Open feature in
Station Data Common Attributes.
Programming
