4.6 Dial Pulse Signaling
Description
An analog CO Line can be configured to send dial pulse signals to the central office. If
programmed as a pulse CO line, the system will send open loop pulses at 10 pps with the
assigned break/make ratio.
Operation
System
Conditions
Operation of this feature is automatic when programmed.
1. The break/make ratio is system programmable as 60/40 or 66/33.
2. You can change the signaling from pulse to DTMF by dialing ‘*’ while on a Line
assigned for pulse signaling.
Programming
CO LINE DATA
Common Attributes

CO Line Type
SYSTEM DATA Pulse Dial (Break/Make) Ratio
System Timers

Pause Timer
Related Features
 Dial Pulse to Tone Switchover
 DTMF Signaling
Hardware
 Analog CO Line
