5.20 Serial DSS/BLF Console
Description
The iPECS IP & LDP Phones can be connected to a Serial DSS/BLF Console to provide
additional Flexible buttons for your use. This can be particularly useful for an Attendant or
Secretarial answering position.
The Console is attached to the phone through a serial cable connection and thus does not
use another station port on the system. For more information about DSS models except the
below, ask your dealer.
 LIP-8012DSS-12 button Console with paper button designation label
 LIP-8012LSS-12 button Console with LCD for button designation label
 LIP-8048DSS-48 button Console with paper button designation label
 LIP-8040LSS-40 button Console with LCD with Triple color LED
 LIP-9012 DSS has 12 flexible buttons with tri-color LED. The DSS button kit
uses a paper label for the button designations.
 LIP-9024 DSS has 24 flexible buttons with tri-color LED. The DSS button kit
uses a paper label for the button designations.
 LIP-9024 LSS has 12 flexible buttons with tri-color LED. The LSS button kit uses
an LCD for the button labels and has two flexible button pages to represent 24
total flexible buttons. The two lower buttons control the page view. The page
button LED will flash when there is new activity under a button on the page. You
can press the page button at any time to change the flexible button page view.
The DSS models employ a paper label strip to designate the function of each button. The
LSS model employs an LCD to designate the button function. The designation for a button on
the LSS model employs standard designations such as STA xxx for a {DSS/BLF} button but
can be modified in the system database to meet your needs.
With some restrictions, you may equip your phone with up to four (4) Serial Consoles. For
installation details, refer to the iPECS UCP Hardware Description and Installation Manual or
Quick Installation guide of each phone.
Operation
iPECS IP Phone
Conditions
Flex buttons on the Serial Console operate the same as the buttons on the phone.
1. The maximum number of Serial Consoles supported in an UCP system is 500 and
no more than 200 can be the LSS model.
2. The iPECS IP Phone model LIP-8004 does not support a Serial DSS/BLF Console.
3. The LIP-8048DSS must always be powered by external adaptor available from
Ericsson-LG Enterprise.
4. An iPECS IP Phone can only provide power to two Serial Consoles, the remaining
