iPECS UCP
Feature Description and Operation Manual Issue 1.3
362
two Consoles must be powered by the external adaptor.
5. A Linked pair secondary station cannot have a Serial Console.
6. When configuring Flex buttons from the phone, the Serial Console Flex buttons
are not used, use the [VOL UP]/[VOL DOWN] buttons to scroll. For example,
when you press the [VOL UP] button the Flex buttons on the phone will represent
the first buttons on the first Console. Note that even though a Console may have
only 12 buttons, the system allocates 48. When programming Flexible button
labels for an LSS, the1st Console starts from button 49, the 2
nd
starts from button
97, the 3rd Console starts from button 145, 4th starts from button 193.
7. As a default, the 48 button Console is assigned with button Map 1 to 4 depending
on the position of the Console. The 12 button Consoles are not assigned a map.
8. If DSS configuration is changed and the phone restarts, programmed DSS data is
initialized from the changed DSS.
9. While idle, the [VOL UP]/[VOL DWN] buttons control the contrast of the LCD of
both the iPECS IP Phone and the LSS model serial.
10. Your station must be enabled to employ a Serial Console, if not enabled, any
connected console will not function.
11. The LIP Phones can also be associated with the standard LIP-8040LSS-40 button
Console with LCD designations. A maximum of nine (9) such consoles can be
associated with a station.
12. LDP-7048DSS-48 button Console with paper button designation labels may be
used with the LDP 7000 series phones. LDP-9048DSS-48 button Console with
paper button designation labels may be used with an LDP 9000 series phone.
Programming
STATION DATA Terminal Attributes Serial DSS Usage
